    Armstrong Whitworth F.K.10 Quadruplane 950mm (PNF)

    Armstrong Whitworth F.K.10 Quadruplane 950mm (PNF)

    You will earn 109 bonus points for buying this item.

    Generating Links

    Armstrong Whitworth F.K.10 Quadruplane 950mm (PNF)


    Price:

    Now save save $0.00 $0.00

    $136.77
    Already Purchased Discontinued Product

    Please continue searching for a similar product.
    1 year warranty
    SKU:
    189000040
    Discontinued Product
    Please continue searching for a similar product.
    want FREE shipping? Click here to find out more!
    Report Issue Not Cheapest?

    Copy and Share the Below URL

    Product Description

    The Armstrong Whitworth F.K.10 was a unique design that never went into full production, it was intended as a 2 seat fighter and light bomber/recconasance aircraft but proved to be inferior to succesful designs already in service. The whole concept of quadruplane's was fairly shortlived but the F.K.10 featured some interesting design features, particularly the all moving tail.....eventually the key to supersonic flight!

    This fantastic looking H-King F.K.10 is made from tough EPO foam and has been superbly finished in a realistic paint scheme complete with authentic waterslide decals. The pre-installed 9g servo's, 35mm Brushless Motor and 30A ESC certainly help to speed up assembly but it would be fair to say that the build is slightly more involved than a monoplane! Like the full size aircraft, this fantastic looking model has some unique features, first is the very scale all-moving tail, just like the real thing, which is mounted on a carbon rod and support by bearings and struts at each end, secondly is the bayonet fitting cowl, a very simple but effective way to install the battery and as you do not plug the battery in until the cowl has been re-fitted, it is also quite safe.

    In terms of flying, the F.K.10 has amazing slow fly capability, the lift of 4 wings combined with the more than ample thrust of the powerful outrunner motor & 10" prop means that the F.K.10 can cruise around at a mere wiff of throttle. The large wheels means that the F.K.10 can handle the roughest of strips, especially as there is plenty of power for take off and landing is a breeze courtesy of the amazingly slow approach speed. As this fantastic looking model uses a nice big 3300mAh 3s pack, flight times are just amazing which is just as well, this model has so much presense that you just won't want to land it!

    Features:
    Superb Scale Finish
    Great Size Model with Tons of Presence
    Amazing Slow Fly Capability
    Pre-Installed Low KV Powerfull Brushless Outrunner
    Simple to Assemble
    Authentic All Moving Tail
    8 Aileron's give excellent Roll Authority
    Bayonet Cowl for Fast Battery Access
    Superb Flight Times
    Large Narrow Wheels Suited to Grass Strips

    Specs:
    Wingspan: 950mm
    Length: 760mm
    Flying Weight: 1100g
    Wing Area: 46.3dm2
    Wing Loading: 23.7g/dm2
    Motor: 3536 Brushless Outrunner 1000kv
    ESC: 30A w/BEC
    Servo: 9g x 4

    Requires:
    Your own 4 Channel TX/RX
    3300mAh 3s Lipoly Battery





    Product Specifications
    Videos
    • F.K 10
    Upload video

    Only registered users can upload video. Please, log in or register

    Discuss 0
    Topics
    Sort by
    Most Recent Topics
    * Nickname:

    * Your Reply:


    Please, enter the text shown in the image into the field below
    CAPTCHA Image
    *Verification Code:
    Cancel
    Submit
    Post a new Topic
    * Nickname:

    * Your Topic:



    Please, enter the text shown in the image into the field below
    CAPTCHA Image
    *Verification Code:
    Post Topic
    Reviews

    Only registered users can write reviews. Please, sign in or sign up

    | Verified Buyer

    • Overall
    • Quality
    • Value

    Certified Buyer Rated

    Mar 13, 2015

    This plane is great, and Hands down very beautiful. My only reason for a 3 star rating is that some of the setup really is trial and error. The instructions are very poorly written and finding resources on the internet is challenging. But once assembled it is a blast to fly and brings lots of looks from those around you!

    Eugene | Verified Buyer

    • Overall
    • Quality
    • Value

    Customer Rated

    Sep 07, 2014

    Great flyer Keep the CG as per instructions and use the rudder a lot. Would write a complete review but this website timed out on me.

    Graham | Verified Buyer

    • Overall
    • Quality
    • Value

    Customer Rated

    Aug 31, 2014

    Have changed my mind now I have started it! I would avoid this kit now! Received mine and found machine gun broken, but glued in, plastic part for holding in undercarriage broken, but not too serious, spar for tailplane missing, but best of all, now that I have started building it, have found it has 3 right hand wing panels and one left hand panel for the middle wings. As my kit it is out of warranty (and unfortunately I have started building it) now having quite a job getting anywhere to just get a spare wing panel.

    | Verified Buyer

    • Overall
    • Quality
    • Value

    Certified Buyer Rated

    Jun 26, 2014

    AHHHH... it is my dream ... just for my hobby room.. so beautifull

    James | Verified Buyer

    • Overall
    • Quality
    • Value

    Customer Rated

    Apr 07, 2014

    Got my plane today. It is reasonably well packed, except I found the cowling has a thumb size crush damage caused by the heavy landing gear packed adjacent to it. The machine gun seemed to e fixed onto the fuselage in a hurry and the instrument sticker slanted! These could have been avoided by leaving them for the user to attach themselves. The skid was also broken off from the fuselage and the damage could also been avoided by leaving them for user to glue them onto the fuselage as part of the build process! For the price, I guess one cannot complain too much about the quality. I have yet to assemble and fly it, but for sure I like to repair and repaint the cowling and perhaps add some CF rods to the wing and fuselage and replace those cheap servos after some flights.

    James Puah

    Sampath | Verified Buyer

    • Overall
    • Quality
    • Value

    Customer Rated

    Feb 01, 2014

    Good Model... No instructions, I just assembled mine, and had to do a lot of guess work, everything fitted perfect like Lego

    Rotork | Verified Buyer

    • Overall
    • Quality
    • Value

    Certified Buyer Rated

    Jul 31, 2013

    The drawings showing the wire rigging left a lot to the imagination. The 30A ESC seems to be too small. The first time I ran the motor up to speed the ESC blew. Otherwise, an interesting model that looks great and hopefully will fly well once the ESC is sorted.

    Pahlevan13 | Verified Buyer

    • Overall
    • Quality
    • Value

    Customer Rated

    Mar 19, 2013

    Test flew it today. 3200 3S battery is way too light, used a 3s 3600 and it was still tail heavy but at least could get it to fly. Extremely pitch sensitive because of the tail heavy condition but at least it flew. major headwinds too which did not help the test flight. Ailerons are effective and should have a good bit of expo on them. The rudder is super effective but will easily cause tip stall so use it carefully.
    It is different which why i bought it. against a background of greenery the camo works exceptionally well so easy to lose orientation. on the other hand it is magnificent in the air so well worth the effort. If you like unusual planes this is one worth having.

    Graham | Verified Buyer

    • Overall
    • Quality
    • Value

    Customer Rated

    Feb 23, 2013

    Just got this kit, how could anyone resist it! Discovered some minor damage in components which could be repaired, but the carbon rod for the tailplane was missing. Complained to HK and was told I would have to return the complete kit to get a replacement rod! They must be joking! Will go to local model shop and buy some carbon spars there. Good model let down by poor quality control.

    RattleSnake | Verified Buyer

    • Overall
    • Quality
    • Value

    Customer Rated

    Jan 06, 2013

    My video review and flight of the F.K 10
    If this link doesn't work search for:

    http://www.youtube.com/watch?v=idRa8qtspC8
    on youtube
