Minim OSD v1.1

Generating Links

Minim OSD v1.1

Price:

Now save save $0.00 $0.00

$22.75
Already Purchased Discontinued Product

Please continue searching for a similar product.
SKU:
387000015
want FREE shipping? Click here to find out more!

This is a mini Arduino based on-screen display board. It's tailored for use with ArduPilot Mega and the MAVlink protocol, and designed to be as small as possible.

It's main components are an ATmega328P 8 bit microcontroller with an Arduino bootloader, and a MAX7456 monochrome on-screen display. Programming is done through an FTDI-compatible 6-pin cable.

It features two independent power and ground sections to isolate the OSD's analog stage: a +5V section for the ATmega and the OSD's digital stage, powered through the FTDI cable or other +5V source; and a regulated +5V section for the OSD's analog stage, powered through the video in/out header and capable of handling up to +12V input.


Features:


• ATmega328P with Arduino bootloader
• MAX7456 monochrome on-screen display
• FTDI cable compatible pinout
• Standard 6-pin ISP header
• Two independent power sections with an LED indicator on each
• Solder jumpers for combining the power sections
• +5V 500mA regulator for up to +12V supply input (5-12v range)
• Solder jumper for PAL video option
• Exposed test points for HSYNC and LOS

Specs:
Voltage: 5-12v
Dimensions: 50 x 18 x 10mm
Weight 4g



Please see the file uploaded under the files tab for Developer credits, Links to source code and other information!

*Note: This is not an original Arduino brand product.

Upload video

Only registered users can upload video. Please, log in or register

Topics
Sort by
Most Recent Topics
* Nickname:

* Your Reply:


Please, enter the text shown in the image into the field below
*Verification Code:
Cancel
Submit
Post a new Topic
* Nickname:

* Your Topic:



Please, enter the text shown in the image into the field below
*Verification Code:
Post Topic

Only registered users can write reviews. Please, sign in or sign up

| Verified Buyer

  • Overall
  • Quality
  • Value

Certified Buyer Rated

Dec 24, 2015

Great OSD! Fully customizable and programmable. Great value for the price and quality. All fans of flying first person - I recommend.

drotschopf | Verified Buyer

  • Overall
  • Quality
  • Value

Certified Buyer Rated

Sep 24, 2015

good OSD, great quality as always

| Verified Buyer

  • Overall
  • Quality
  • Value

Certified Buyer Rated

Aug 18, 2015

Good quality.

Works immediately.

| Verified Buyer

  • Overall
  • Quality
  • Value

Certified Buyer Rated

Aug 14, 2015

These things are amazing. Someone even figured out how to get FrSky telemetry on this.

jtaliaferro | Verified Buyer

  • Overall
  • Quality
  • Value

Certified Buyer Rated

Jun 21, 2015

OSD works a treat with APM 2.6. Update the firmware with a ftdi and you have a good osd.

| Verified Buyer

  • Overall
  • Quality
  • Value

Certified Buyer Rated

May 21, 2015

Cheap and powerful, these will connect to the Naze32, MultiWii, APM, and Pixhawk. Out of the three I've bought, one has succumbed to a voltage spike. This was most likely caused by a crash and not a defect in the product itself. In general, I'm very happy with these.

lee | Verified Buyer

  • Overall
  • Quality
  • Value

Customer Rated

May 08, 2015

bought this osd to go with my first MultiWii.

though not setup out the box to work with MW boards (set for APM & PIXHAWK standard) theres tons of simple info and advice available all over the place and as this OSD is long established there are many available firmwares to suit just about any FC out there, Took a noob like me half an hour to flash new firmware via a Ftdi adapter and configure the display before I was out and in the air with my new OSD working a treat. WORTHY OF NOTE(as not mentioned here).... The V1.1 and newer versions DO NOT suffer the same overheat failures that the earlier versions did so the 12v side of the board can now be happily fed with a 12v feed (as was intended)

| Verified Buyer

  • Overall
  • Quality
  • Value

Certified Buyer Rated

May 05, 2015

??????????? ????? ? ???? ???????= ???????? - ??? ???????? ) ?????? ????? ?????? ? ?? ??????? ) ??? ?????? ???????? ) ?? ?????????????? ???????? ???????????? )

naxos | Verified Buyer

  • Overall
  • Quality
  • Value

Customer Rated

Mar 29, 2015

Very nice Osd with an awesome price! You can have all the information from this little board but be careful if you are a newbie because it requires some skill! It's not plug and fly but once correclty setup it works like a charm. there are a lot of useful videos on how to program and install it.

Alexander | Verified Buyer

  • Overall
  • Quality
  • Value

Customer Rated

Mar 24, 2015

Two units was bought. MCU (not video chip) of the first one fried after two days of usage. After replacement of the dead MCU I have the same problem- inadequate temperature of the MCU. Nevertheless it still working after putting heat sink on the chip.
Second unit works perfectly except one thing: it is impossible to configure it through the serial link as the Tx channel of the OSD is dead. The quality of this product is really disappointing.
