Quanum Trifecta Mini Foldable Tricopter Frame (KIT)

Quanum Trifecta Mini Foldable Tricopter Frame (KIT)

Now save save $26.82 $26.82

Special Price $4.99 $4.99

You save save $26.82 $26.82

Was  $31.81

Status:
Out of stock!
SKU:
9171000576-0
WANT FREE SHIPPING? Click here to find out more!

With versatility being the name of the game and foldable for easy of transportation, the Quanum Trifecta is the most fun you can have with something that fits in your pocket.

Being a long time in the works and having gone through many revisions, the Trifecta started life as a portable line of sight acro tricopter. Through development and FC options becoming smaller and more powerful, a frame emerged that was not just good at different roles, but excellent at any type of application it was tasked.

The Trifecta is highly portable, folding down to just 150x80mm and yet opened up is nearly 300mm for an extremely stable and maneuverable platform. The frame has provisions for almost all conceivable gear starting with a huge FC bay fitting the CC3D, Naze32, KK Mini or even the HKPilot Mini. There are mounting points for an FPV transmitter, telemetry radio, GPS, RX, ESC's, power modules, and best of all is the included vibration isolated front mounts for both the Mobius and GoPro line of cameras.

The Trifecta is highly agile and capable of maneuvers that weren't possible with frames that came before it. Along with that, the frame can be loaded with FPV gear, GPS and telemetry for a FPV or UAV roles such as follow me applications and autonomous flights where size and portability is key.

The frame is made from glass filled molded nylon for a strong and lightweight base, the tilt drive is all metal gear driven for a fast crisp yaw response using a 9g servo. The motor mounting supports 14~19mm cross style mounting and 5~8inch props can be used.

The Trifecta will become your go-to multirotor with its portability, versatility and its ability to leave you smiling.

Features:
• Collapsible/foldable to just 150mm
• 6~8inch propeller
• Built in PDB
• Huge flight controller bay
• GPS mount
• FPV and telemetry mount
• Mobius or GoPro isolated mount
• Wide range of motor and ESC options
• Metal tilt drive
• Durable glass filled Nylon construction
• Acrobatic fun, FPV or Pocket UAV adaptable

Specs:
Weight: 160g
Wheelbase: 295mm opened (150mm collapsed)
Propellers: 5~8 inch (6~7 recommended)
ESC's: 10~20A (Afro 12A recommended)
Motor: 2206~2209 class (2206 recommended) 14~19mm slot mounting (sold separately)
FC: CC3D,Naze32,KK Mini, HKPilot Mini or similar size (sold separately)
Servo: TGY-9018 MG (sold separately)

Included:
Quanum Trifecta frame kit
Power distribution board
Battery strap
Hardware and cable ties

Required:
Motors: 3 x 2206~2209 class (2206 'Baby Beast' motors recommended) 14~19mm slot mounting
ESC's: 3 x 10~20A (Afro 12A recommended)
Flight Controller: CC3D, Naze32, KK Mini, HKPilot Mini or similar size
Propellers: 3 x 5~8 inch (Gemfan HQ 6045 recommended)
Lipoly: 1000mah~1400mah 3S Lipoly (MultiStar 1400 Race Spec recommended)
Servo: 1 x 9G metal geared servo (TGY-9018 MG)

*Note: A Turnigy TGY-9018MG Metal Gear Servo is required

  • SKU 9171000576-0
  • Brand Quanum
  • Capacity (mAh) -
  • Shipping Weight 495.0000
  • Length 255.00
  • Width 50.00
  • Height 175.00
  • Quanum Trifecta Mini Foldable Tricopter Frame
Upload video

Only registered users can upload video. Please, log in or register

Only registered users can write reviews. Please, sign in or sign up

Buena plataforma tricoptero... 1 dia en armar.
con motor Mini Beast es un buen kit!!
helice 5040.
Pongan MAS EN STOCK!!!

playlist_add_check Overall:
trending_up Value:
verified_user Quality:

Buena plataforma tricoptero... 1 dia en armar.
con motor Mini Beast es un buen kit!!
helice 5040.
Pongan MAS EN STOCK!!!

excellent frame, got it for 5$.
Everything is thought of, but it is a bit crammed.
front arms are a bit shakey, and landing gear is unreliable..

playlist_add_check Overall:
trending_up Value:
verified_user Quality:

excellent frame, got it for 5$.
Everything is thought of, but it is a bit crammed.
front arms are a bit shakey, and landing gear is unreliable..

I was looking for something different and found it in the Trifecta, the build was relatively easy although it pays to take your time with the cabling to get it as neat as possible, I choose small OPTO ESCs and a UBEC. If I were building another one I would use 2 OPTO ESCs on the arms and an ESC with BEC inside the frame to save room. The Trifecta flies great, more like flying a fixed wing then a quad very responsive. The only complaint that I have is the lack of spares for the frame if you ever break anything you are going to have to buy a new frame.

playlist_add_check Overall:
trending_up Value:
verified_user Quality:

I was looking for something different and found it in the Trifecta, the build was relatively easy although it pays to take your time with the cabling to get it as neat as possible, I choose small OPTO ESCs and a UBEC. If I were building another one I would use 2 OPTO ESCs on the arms and an ESC with BEC inside the frame to save room. The Trifecta flies great, more like flying a fixed wing then a quad very responsive. The only complaint that I have is the lack of spares for the frame if you ever break anything you are going to have to buy a new frame.

Totalt, dette er godt utformet tricopter. Det eneste problemet jeg hadde var plast utstyr som er festet til servo. Som HK har acknowleged, utstyret var d?rlig maskinert og ikke kunne passe min servo. Kontakte deres Customer Support var ubrukelig. Ingen reagerte da jeg ?pnet en billett. Jeg ?pnet en andre to dager senere og fortsatt ingen respons. Jeg fant en midlertidig satt opp som vil fungere for en stund. Godt produkt, d?rlig kundeservice.

verified_user Quality:
trending_up Value:
playlist_add_check Overall:

Totalt, dette er godt utformet tricopter. Det eneste problemet jeg hadde var plast utstyr som er festet til servo. Som HK har acknowleged, utstyret var d?rlig maskinert og ikke kunne passe min servo. Kontakte deres Customer Support var ubrukelig. Ingen reagerte da jeg ?pnet en billett. Jeg ?pnet en andre to dager senere og fortsatt ingen respons. Jeg fant en midlertidig satt opp som vil fungere for en stund. Godt produkt, d?rlig kundeservice.

Amazing!! So many extras, really strong and well made (not to mention brilliantly designed). If you want a small tri, that you can bring with you wherever you want, this is the one.

verified_user Quality:
trending_up Value:
playlist_add_check Overall:

Amazing!! So many extras, really strong and well made (not to mention brilliantly designed). If you want a small tri, that you can bring with you wherever you want, this is the one.

Outstanding frame. Swapped the recommended servo for emax es09md digital servo. Folds down to a miniscule size! Runnin 2208 2800kv with gf7038 on 3s.

verified_user Quality:
trending_up Value:
playlist_add_check Overall:

Outstanding frame. Swapped the recommended servo for emax es09md digital servo. Folds down to a miniscule size! Runnin 2208 2800kv with gf7038 on 3s.

The most satisfying build to date.
Good kit and instructions.
Don't rush it, I used DYS micro ESCs 20A 7g, King Kong Mini CC3D, recomended servo and a 1400mAh 3S.
With Mobius and a 600mW video system 505g all in.
Performance is great and fluid, I will get a second frame just for spares.
1 niggle, legs are too short, International warehouse stocking longer legs and if they come in stock in Europe will buy, otherwise will print.

verified_user Quality:
trending_up Value:
playlist_add_check Overall:

The most satisfying build to date.
Good kit and instructions.
Don't rush it, I used DYS micro ESCs 20A 7g, King Kong Mini CC3D, recomended servo and a 1400mAh 3S.
With Mobius and a 600mW video system 505g all in.
Performance is great and fluid, I will get a second frame just for spares.
1 niggle, legs are too short, International warehouse stocking longer legs and if they come in stock in Europe will buy, otherwise will print.

ottimo telaio ben progettato nel suo piccolo c'? spazio per tutto!

verified_user Quality:
trending_up Value:
playlist_add_check Overall:

ottimo telaio ben progettato nel suo piccolo c'? spazio per tutto!

A multirotor[1] or multicopter is a rotorcraft with more than two rotors. An advantage of multirotor aircraft is the simpler rotor mechanics required for flight control. Unlike single- and double-rotor helicopters which use complex variable pitch rotors whose pitch varies as the blade rotates for flight stability and control, multirotors often use fixed-pitch blades; control of vehicle motion is achieved by varying the relative speed of each rotor to change the thrust and torque produced by each.



Due to their ease of both construction and control, multirotor aircraft are frequently used in radio control aircraft and UAV projects[2][3][4][5][6][7] in which the names tricopter, quadcopter, hexacopter and octocopter are frequently used to refer to 3-, 4-, 6- and 8-rotor helicopters, respectively.[8]





Hexacopter.[9]

In order to allow more power and stability at reduced weight coaxial rotors can be employed, in which each arm has two motors, running in opposite directions (one facing up and one facing down).[10]1234

verified_user Quality:
trending_up Value:
playlist_add_check Overall:

A multirotor[1] or multicopter is a rotorcraft with more than two rotors. An advantage of multirotor aircraft is the simpler rotor mechanics required for flight control. Unlike single- and double-rotor helicopters which use complex variable pitch rotors whose pitch varies as the blade rotates for flight stability and control, multirotors often use fixed-pitch blades; control of vehicle motion is achieved by varying the relative speed of each rotor to change the thrust and torque produced by each.



Due to their ease of both construction and control, multirotor aircraft are frequently used in radio control aircraft and UAV projects[2][3][4][5][6][7] in which the names tricopter, quadcopter, hexacopter and octocopter are frequently used to refer to 3-, 4-, 6- and 8-rotor helicopters, respectively.[8]





Hexacopter.[9]

In order to allow more power and stability at reduced weight coaxial rotors can be employed, in which each arm has two motors, running in opposite directions (one facing up and one facing down).[10]1234

Very compact and neat little tricopter for easy transportation
Full config detailed on http://tricopters.blogspot.com/
tricopters blogspot com
Enjoy

verified_user Quality:
trending_up Value:
playlist_add_check Overall:

Very compact and neat little tricopter for easy transportation
Full config detailed on http://tricopters.blogspot.com/
tricopters blogspot com
Enjoy
