Turnigy SK3 Fandrive - 3994-850kv (120mm EDF)

Turnigy SK3 Fandrive - 3994-850kv (120mm EDF)

Shipped From:
  • USA
  • Global
QTY:

Now save save $0.00 $0.00

$91.60
Status:
Backorder
SKU:
120EDF-3300KV
WANT FREE SHIPPING? Click here to find out more!

Turnigy SK3 Motors are the next leap forward in motor quality and design. We instructed the engineers to source the best quality magnets, bearings and materials available to them and develop a motor that would not only rival, but surpass the quality of many leading motor manufactures on the market today.

The result is an efficient, high caliber motor using quality double shielded bearings, sintered Neodymium magnets and a string wound stator ensuring an accurate and consistent winding each and every time.

The Turnigy SK3 motors are suited to modelers who are seeking a quality brushless motor without compromise.

Specs.
Motor Type: 4 Pole Inrunner
Winding: 2.5D
Voltage: 12S Lipoly
RPM/V: 850kv
Internal resistance: 0.012 Ohm
Max Loading: 90A
Max Power: 3950W
Shaft Dia: 8.0mm
Weight: 554g
Motor Plug: 4mm Bullet Connector

  • SKU 120EDF-3300KV
  • Brand SK3
  • Shipping Weight 788.0000
  • Length 140.00
  • Width 50.00
  • Height 100.00
  • Kv(rpm/v) 850.00
  • Max Current (A) 90.00
  • Resistance (mh) 0.00
  • Max Voltage(V) 43.00
  • Power (W) 3950.00
  • Shaft A(mm) 8.00
  • Length B (mm) 96.00
  • Diameter C(mm) 39.00
  • Can Length D(mm) 95.00
  • Total Length E(mm) 125.00
  • Turnigy Super EDF SK3 Motor
Upload video

Only registered users can upload video. Please, log in or register

Only registered users can write reviews. Please, sign in or sign up

This motor is ideal for the impeller 12 Blade High-Performance 90mm EDF Ducted Fan Unit and achieves traction 5.5kg (12 lb) at a current of 99 amps, 44 volts at a voltage of 2 pieces Turnigy nano-tech 8000mAh 6S 25 ~ 50C Lipo Pack and Power 4320 watts /
at a current of 90 amperes at a voltage of 44 volts and 4000 watts load capacity 5.15 kg of thrust (11,3 lb). Have a pleasant flight.

verified_user Quality:
trending_up Value:
playlist_add_check Overall:

This motor is ideal for the impeller 12 Blade High-Performance 90mm EDF Ducted Fan Unit and achieves traction 5.5kg (12 lb) at a current of 99 amps, 44 volts at a voltage of 2 pieces Turnigy nano-tech 8000mAh 6S 25 ~ 50C Lipo Pack and Power 4320 watts /
at a current of 90 amperes at a voltage of 44 volts and 4000 watts load capacity 5.15 kg of thrust (11,3 lb). Have a pleasant flight.

Very nice motor.

12S 5000mah 30C, Zippy

120amp Castle (low timing) (180amp Turnigy Delux would not handle it)

120mm 4 blade ChangeSun Fan (sold here)

Results

85 amps, 3500watts and 10.5lbs static thrust

Warm but not hot.

verified_user Quality:
trending_up Value:
playlist_add_check Overall:

Very nice motor.

12S 5000mah 30C, Zippy

120amp Castle (low timing) (180amp Turnigy Delux would not handle it)

120mm 4 blade ChangeSun Fan (sold here)

Results

85 amps, 3500watts and 10.5lbs static thrust

Warm but not hot.

Great motor, could use larger cooling holes in can. Would like to see a more versatile version as shaft is 25mm long, would like a shorter shaft of 12mm so as to be able to fit onto Haoye fans.

Would also like to see a 1200KV version for 8S and 10S use.

Make it happen HK, would definately improve sales if people can utilise this motor in fans other than CS 120mm.

Good motor overall.

verified_user Quality:
trending_up Value:
playlist_add_check Overall:

Great motor, could use larger cooling holes in can. Would like to see a more versatile version as shaft is 25mm long, would like a shorter shaft of 12mm so as to be able to fit onto Haoye fans.

Would also like to see a 1200KV version for 8S and 10S use.

Make it happen HK, would definately improve sales if people can utilise this motor in fans other than CS 120mm.

Good motor overall.

Customer files
No File Name Download [86]
SK3 with Lander 120mm DF Download [86]
Upload your file

Only registered users can upload files.
Please log in or register to start helping your fellow hobbyists today!
