Looking for a 10 channel radio system complete with on board telemetry? The Turnigy TGY-i10 has arrived! The TGY-i10 is bursting with features which are perfect for the modeller who requires maximum control and real time telemetry.
The TGY-i10 uses 2.4GHz AFHDS 2 (automatic frequency hopping digital system 2) which spans the whole frequency band. Equipped with a high sensitivity receiver, this radio system guarantees an optimal and highly secure link between the transmitter and receiver.
The innovative design of the new TGY-i10 makes the handset extremely lightweight while the menu items and data is presented on its 3.55 inch TFT touch screen!
The TGY-i10 radio system uses high gain, high quality multi directional antennas, each transmitter has a unique ID, when binding, the receiver saves that unique ID and will only accept signals from the transmitter it is matched with, this prevents interference from any other radios and ensures the safety of your model.
The TGY-i10 radio system utilizes extremely efficient components and high speed processor chips for those complicated mixing settings. In comparison this radio system uses 1/10th of the power of a standard FM system.
Another key feature of the TGY-i10 is its telemetry capabilities, the radio system has the ability to monitor real time rpm / voltage and temperature data which provides added security when flying your models.
If you require more than 10 channels an i-Bus receiver (TGY-AEV01) is included, which will provide you with an extra 4 channels which allows an additional 16 servos to be connected.
The TGY-i10 really is one of the most intelligent and innovative radio systems available today and all at a price that will not break the bank!
Features:
• 2.4 GHz AFHDS 2 (automatic frequency hopping digital system)
• Compatible with all TGY AFHDS receivers
• Real time telemetry monitors signal strength, Rx voltage, flight pack voltage, RPM and temperature
• Audio and visual warnings when limits are exceeded
• 3.55 inch, 240 by 400 pixels (WQVGA) colour, high contrast TFT-LCD touch screen
• Power on/off safety feature
• 3 way switch x 2, 2 way switch x 5, momentary switch x 1 and slider control switch x 2
• Easy access pop up / down VR controllers x 3
• High-precision double ball bearing gimbal and ergonomic design
• Double antenna structure for improved signal transmission
• 20 model memory including memory expansion slot
• Free software upgrades available online
Transmitter Functions Include:
General functions: Flight conditions, linear / curve mixing, functions / channel / throttle delays, channel mixing, logic switches, Aircraft type, RX setup, dual rates / expo, endpoint adjustment, channel offset, trim / subtrim, throttle down / curve / delay / reverse, system menu, model name, timers etc.
Airplane / Glider functions: Aileron / flap / spoiler, elevator to flap, butterfly, V-tail, dual elevator etc.
Helicopter functions: Throttle hold / mix / curve, pitch curve, swashplate mixing / type / ring, governor, gyroscope etc.
Specs:
Channels: 10
Model Type: Helicopter / airplane / glider
RF Range: 2.4055-2.475GHz
bandwidth: 500KHz
Band: 140
RF Power: Less than 20 dBm
2.4G system: AFHDS2A
Code type: GFSK
Low Voltage Warning: Yes (less than 3.75V)
DSC port: Yes (USB, HID)
Memory Expansion: SD card
Antenna Length: 26mmx2
Weight: 620 grams (with battery)
Battery Capacity: 3.7V (1700mAh)
Dimension: 195 x 189 x 43mm
Package Includes:
(TGY-iA10) 10 Channel 2.4GHz receiver
(TGY-BA1700) Li-ion battery 1700mah
(TGY-ATM01) Thermometer sensor
(TGY-AVT01) Voltage sensor (optical module)
(TGY-APD02) RPM sensor
(TGY-AEV01) I-bus receiverMicro USB cable
Trainer Cable
Stylus pen
User Manual (CD)
*Firmware upgrade
Version: TGY-i10 19-3-2015
This update fixes some bugs and adds refinements to the programming. It also improves the overall stability of the system.
Warning! Please make sure all your current models on the TGY-i10 must be stored on a SD card before you proceed to firmware upgrade. Otherwise all the model memories in the transimitter will be lost.
Please find the upgrade firmware in the files tab.
-
