GEP210 Carbon Fiber FPV Racing Drone / Freestyle frame Kit

The GEP210 racer frame has an ultra-low center of gravity, design which makes the airframe much more stable than the rest of the competition! The benefits of a lower surface center of gravity means the airframe offers superior turning and rolling making it the ideal frame for the freestyle fanatics and racers alike!

The electronics bay is housed within the frames highly durable 3mm, 3k weaved carbon fiber chassis which provides excellent protection for your electronic components during high-speed collisions or crashes. The entire weight of the airframe is concentrated on the center line of the model, which adds stability while making your setup far more efficient.

The LED lighting plate for the back of the GEP210 frame has 6, WS2812 super bright programmable LEDs (controlled by your flight controller). The supplied camera mount allows you to adjust the angle up to 45 degrees for high-speed flight. The kit also includes a lightweight and compact PDB with built in BEC with 5-12V output.

The GEP210'S battery is mounted on top of the quad keeping the weight at the same level as the motors to ensure the center of gravity remains even throughout. The GEP210 also offers plenty of space to allow you to fit a multitude of battery sizes with its 106 x 37mm platform.

Features:
• Highly durable 3mm thick 3k weave carbon fiber
• Super low center of gravity design
• Includes distribution board (PDB) with integrated BEC (5-12v output)
• Programmable tail light LED plate
• Aluminum CCD camera mount plate
• 45 degree camera angle adjustment
• 1.5mm upper deck thickness
• Supplied with 10 x CNC aluminum M3x15mm frame stacks
• Large battery platform 106 x 37mm

Specs:
Frame Diameter: 210MM
Frame Weight: 98g
Frame Material: 3K weave carbon fiber

Recommended:
1806/2204/2206/2208 2300kv brushless motors
4-5 inch props (CW/CCW)
F3 autopilot / Naze32 / CC3d flight controller
15-20A brushless speed controller

Please Note: The tail lights requires a flight controller with LED program functions to operate
