YEP 120A HV (4~14S) Brushless Speed Controller (OPTO)

YEP 120A HV (4~14S) Brushless Speed Controller (OPTO)

QTY:

Now save save $0.00 $0.00

$127.32
Rating:
Stock:
Weight:
237 g
SKU:
9355000019

Suggestion Box

Please let us know if you found any issues with this product listing.
We take our customer comments very seriously and in many cases our website modifications and product updates are a result of your comments!

Price War

If you've seen a product elsewhere for a better price, please let us know! HobbyKing pride themselves on offering the best price, so if there if you see something cheaper elsewhere, let us know!

Combine

essential items and
acc
Product
Description

YEP ESC series offers a super smooth linear throttle responce making them exceptional fixed wing and helicopter ESCs.  The features offered in this ESC are only matched by the most expensive european brands at a fraction of the cost. The super smooth soft start, along with its ultra high resolution throttle response puts this ESC in a class of its own!

YEP ESCs are built with the highest quality components to ensure true-to-rating current handling and high efficiency operation. Although quality is a tag line mentioned by many manufacturers you'll notice the difference the moment you remove the YEP ESC from the box.

All YEP ESCs can be programmed via optional programing card or by transmitter stick inputs.



Features:
• HV capability for use with up to 14S (51.8V) Lipoly
• Optional programming card for convenient setup
• ESC had separate programming lead built-in so there is no need to unplug from RX
• Super fine throttle resolution provides first-rate and highly accurate linearity
• Super smooth adjustable start-up mode
• Constant RPM mode (governor mode)
• Adjustable F3A brake.
• 3 steps adjustable normal EMF brake
• High anti-interference capability
• Low voltage cut-off protection with automatic adjustment for NiCd/NiMH/Li-Ion/LiPo/LiFePO4
• Soft cut-off option at low voltage, slows motor RPM gradual rather than hard cutoff (LVC)
• Low voltage cut-off can be disabled
• Variable cut-off voltage / cell
• Active free-wheeling circuit allows for unlimited "partial load" capability
• LED status display
• Adjustable motor timing from 0° to 30°
• Blocked rotation protection (senses a jammed motor and stops motor rotation)
• Over-temperature protection and overload alarm
• Anti sparking circuit: reduces connection sparks
• Throttle signal lose protection. If the signal is lost for 3 seconds, the power will automatically cut-off.
• Safe power-on. (Motor will not start until throttle is returned to lowest position)


Specification:
Max Cont Current: 120A
Max Burst Current: 140A for 10 seconds
Input Voltage: 4-14 cells li-XX or 12-42 Ni-MH/Ni-Cd battery
BEC: None (OPTO)
PWM: 8~16 KHz
Max RPM: 240,000rpm for 2 Poles Brushless Motor
PCB Size: 68x53mm
Weight: 164g (including wires)


Recommended
YEP programming card required to access the full suit of programming options.

Product
Specifications

Additional Information

  • SKU:
    9355000019
  • Brand:
    HobbyKing
  • Weight(g)
    237.00
  • Length
    165.00
  • Width:
    55.00
  • Height:
    65.00
Community
Discussions
Rate&
Review

Write Your Own Review

Only registered users can write reviews. Please, sign in or sign up

verified_user Quality
trending_up Value
playlist_add_check Overall
I use this on my assault 700 and it works fine, it doesnot get too hot after 7 min flight...
verified_user Quality
trending_up Value
playlist_add_check Overall
verified_user Quality
trending_up Value
playlist_add_check Overall
This ESC is very bad quality.
I tried iti with 510 kv motor and 12s lipo for 120 mm EDF. Only half trottle it burned.
I never buy cheap HV ESC. Low volt ESC no problem but HV never.
verified_user Quality
trending_up Value
playlist_add_check Overall
verified_user Quality
trending_up Value
playlist_add_check Overall
Der Regler lief gut an einem RotoMax 1.60. Allerdings nur im Default-mäßig eingestellten "Softanlauf". Nach dem Umkonfigurieren in einen etwas schnelleren Anlauf starb der Regler.
verified_user Quality
trending_up Value
playlist_add_check Overall
verified_user Quality
trending_up Value
playlist_add_check Overall
Burnt mofset in 5 seconds on maiden flight. Thank god my 8S JP EDF- 90 never left the runway and for the BEC setup. bench tested with no problems. Going to attempt replacing mofsets, but bothersome not knowing how this happened with reverse polarity and all the other "protections"
verified_user Quality
trending_up Value
playlist_add_check Overall
verified_user Quality
trending_up Value
playlist_add_check Overall
Nutz(t)e zwei von diesen Reglern in einem 1.35m Cat. Die Regler qualmen beim Hochgehen weitaus weniger als das deutsche Pendant. Hobbyking hat hier sehr gut weiterentwickelt und zerstörende Brände im Rumpf effektiv unterbunden. Ebenso konnte der Gestank gegenüber dem Original auch nochmal deutlich reduziert werden. Schon nach wenigen Tagen lüften riecht der GFK Rumpf kaum noch.
TOP REGLER!!
verified_user Quality
trending_up Value
playlist_add_check Overall
verified_user Quality
trending_up Value
playlist_add_check Overall
This is a great ESC using with an Align BL750MX motor no problems............
I run YGE/YEP on every model.... Never had a problem... Just remember the program card MUST HAVE 5v input to store your program.... So don't use the little 4.8 Volt receiver packs to program with. NEXT..... always use the TX sticks to set end points.....

verified_user Quality
trending_up Value
playlist_add_check Overall
verified_user Quality
trending_up Value
playlist_add_check Overall
Unschlagbar fr den Preis..und mit meiner vorhandenen YGE ProgCard zu proggen..TOP
verified_user Quality
trending_up Value
playlist_add_check Overall
verified_user Quality
trending_up Value
playlist_add_check Overall
the best the best the best the best the best
verified_user Quality
trending_up Value
playlist_add_check Overall
verified_user Quality
trending_up Value
playlist_add_check Overall
Worth everything for your high power setup :) Using with 8S 5000 on a HET motor and wemotec 90mm EDF. Barely warm with pulling 3400W and 108 Amps. GREAT product and easy to program. Plugging everything together is a little tricky with the programming card, but you'll know if you do it right.
verified_user Quality
trending_up Value
playlist_add_check Overall
verified_user Quality
trending_up Value
playlist_add_check Overall
Super Regler zum super Preis.
Die "alten" Mngel wie schlechte Kabelfhrung behoben.
Mein Goblin hat eine echte Freude damit.
Verwendete bisher YGE - sehe keinen Grund mehr.....
verified_user Quality
trending_up Value
playlist_add_check Overall
